Ajay Engineering

SPP-SERIES PUMP PARAMETERS
CONSTRUCTION DETAILS
The SPP Series pumps are having a Cast-Iron or Mild-Steel outer construction with Stainless Steel Internals including Rotor. The Stator is made up of Nitrile or other suitable material based upon the Liquid properties. The Suction & Discharge Ports are offered in Flanged End Connections.
APPLICATIONS
The SPP Series pumps are offered to cater liquids such as Oil Sludges, Effluent Sludges, Acids, Acrylic, Ceramic, Chemical Slurries, Emulsions, Paints, Yeast, Magma, Molasses, Oils, Printing Inks, Solvents, Vegetable Oil etc.
PUMP CAPACITY
FLOW RATE	UP TO 100 m³/hr
PRESSURE	UP TO 20 bar
TEMPERATURE	UP TO 120℃

SPF-SERIES PUMP PARAMETERS
CONSTRUCTION DETAILS
The SPF Series pumps are specially offered for Food-Grade pumping needs having a hygienic & food grade complaint construction. All the Liquid Contact parts are made up of food grade Stainless Steel material while the rotor & stator is made up of food grade rubber. The Suction & Discharge ports are offered in SMS Union Nut.
APPLICATIONS
The SPF Series pumps are offered to cater liquids such as Apple Pulp, Beer, Mango Pulp, Beverages, Curd, Butter Oil, Cream, Glucose, Jam, Yeast, Fruit Pulps, Medical Formulates etc.
PUMP CAPACITY
FLOW RATE	UP TO 100 m³/hr
PRESSURE	UP TO 20 bar
TEMPERATURE	UP TO 120℃

SPW-SERIES PUMP PARAMETERS
CONSTRUCTION DETAILS
The SPW Series pumps are specially designed for handeling High-Viscous Products or Powder Products which contains moisture content. The Connecting Rod is specially designed as screw type which manouvers the solid particles easily resulting in efficient pumping. The Suction End is made as Wide-Throat to enable store solid particles avoiding dry runs.
APPLICATIONS
The SPW Series pumps are offered to cater liquids such as Asbestos Slurry, Butter, Cake Mix, Clay Slurry, Fruit, Explosive Slurry, Starch Slurry, Yogurt, Lecithin, Cement Slurry etc.
PUMP CAPACITY
FLOW RATE	UP TO 100 m³/hr
PRESSURE	UP TO 20 bar
TEMPERATURE	UP TO 120℃
